Passive Target Trihedrals

TACT's Passive Target Trihedrals provide a very high Radar Cross Section (RCS) response/target for a wide range of frequencies for radar testing, characterization and range finding. Additional elevation and azimuth mounting allow accurate alignment with the transmitting radar which greatly reduces clutter caused by terrain and other obstacles.

Laser cut trihedral arrays are made from highly durable 3mm A grade 6082 T651 aluminum sheet ensure a precision product. Available with straight, curved or square sections up to 160cms to suit your particular Target response or angle requirements we also make a special version as a test target for formal IEC : 62388 (ed2) 2013 Standard radar and RED testing, as shown on separate listing.

New modular trihedrals made from perforated 2mm thick 1050 aluminium offer light weight & reduced wind resistance with quick assembly/disassembly for portability and easy storage.

Target sight option available. Mounting options:- adjustable wall bracket, adjustable tripod, vehicle or marine.

Please allow approximately 90 business days for delivery.
